PART NO.

規格/編碼

ITEM NO.

品名型號

尺寸DIMENSIONS(mm)

Φd 2

B

L

ΦD

Φd

E

CL14-HM6

CL14-H-6

6.4

18.3

50

8.8

5.8

28.5

CL22-HM8

CL22-H-8

8.4

18.3

52

11.3

7.7

28.5

CL38-HM10

CL38-H-10

10.5

18.3

64

12.4

9.8

34

CL38-HM12

CL38-H-12

13

18.3

64

12.4

9.8

34

CL60-HM10

CL60-H-10

10.5

20.5

70

14

11

36

CL60-HM12

CL60-H-12

13

20.5

70

14

11

36

CL70-HM10

CL70-H-10

10.5

21.4

72

15

12

38

CL70-HM12

CL70-H-12

13

21.4

72

15

12

38

CL80-HM12

CL80-H-12

13

23.2

75

16

13

38

CL100-HM12

CL100-H-12

13

26

75

18

14

40

CL125-HM12

CL125-H-12

13

29

85

20

16

40

CL150-HM12

CL150-H-12

13

31.5

94

22

17

46

CL180-HM12

CL180-H-12

13

33

98

23

18.2

46

CL200-HM12

CL200-H-12

13

37

104

26

20

48

CL250-HM12

CL250-H-12

13

40

114

28

22

48

CL325-HM12

CL325-H-12

13

46

118

32

25

50

CL400-HM12

CL400-H-12

13

54

130

37

30

60

CL500-HM12

CL500-H-12

13

57.5

150

40

31

60

PART NO.

規格/編碼

ITEM NO.

品名型號

尺寸DIMENSIONS(mm)

Φd 2

B

L

ΦD

Φd

E

B-CL14-HM6

B-CL14-H-6

6.4

18.3

50

8.3

5.8

28.5

B-CL22-HM8

B-CL22-H-8

8.4

18.3

52

10.7

7.7

28.5

B-CL38-HM10

B-CL38-H-10

10.5

17.2

64

11.9

9.8

34

B-CL38-HM12

B-CL38-H-12

13

17.2

64

11.9

9.8

34

B-CL60-HM10

B-CL60-H-10

10.5

20

70

13.5

11

36

B-CL60-HM12

B-CL60-H-12

13

20

70

13.5

11

36

B-CL70-HM10

B-CL70-H-10

10.5

21.4

72

14.5

12

38

B-CL70-HM12

B-CL70-H-12

13

21.4

72

14.5

12

38

B-CL80-HM12

B-CL80-H-12

13

23.2

75

15.5

13

38

B-CL100-HM12

B-CL100-H-12

13

25.5

75

17.3

14

40

B-CL125-HM12

B-CL125-H-12

13

28

85

19.3

16

40

B-CL150-HM12

B-CL150-H-12

13

30.5

94

21.1

17

46

B-CL185-HM12

B-CL185-H-12

13

32.5

98

22.1

18.2

46

B-CL200-HM12

B-CL200-H-12

13

36

104

24.9

20

48

B-CL250-HM12

B-CL250-H-12

13

39.5

114

26.9

22

48

B-CL325-HM12

B-CL325-H-12

13

45

118

30.7

25

50

B-CL400-HM12

B-CL400-H-12

13

53.5

130

35.7

30

60

B-CL500-HM12

B-CL500-H-12

13

56

150

38.4

31

60
